Electrical Characteristics
Specifications
·Circuit: 1P2T
·Switch function: On-On
·Rating: 0.3A 50VDC
·Contact resistance: 30mΩ Max. at 5VDC
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 500VAC for 1 minute
·Timing: Non Shorting
·Operating force: 300±100g
·Life cycle: 10,000 cycles Max.
