Specifications

·Power rating: 180W
·Number of ports: 2
·Data rate: 10M/100M/1G/2.5G/5Gbps
·PoE power supply type: End-span + Mid-span
·PoE power output budget: 120W Max. @48VDC, 180W Max. @52V/54VDC
·Per PoE port output power: 95W
·Interface
Input port: 2 x RJ45 STP (data+power) in
Output port: 2 x RJ45 STP PoE(data+power) out
DC socket: 48V ~ 54V DC input socket, 2.5A Max.
·Network cable:
Twisted-pair cable up to 100 meters (328ft)
10Base-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6
100Base-TX: 4-pair UTP Cat. 5, 5e, 6
1000Base-T: 4-pair UTP Cat. 5e, 6
2.5G/5GBase-T: 4-pair UTP Cat.6, 6A,7
·LED indicators
Power Leds: Power 1 and power 2
PoE usage: 60W, 120W and 180W
·Operating temperature: -40°C to +75°C
·Storage temperature: -40°C to +75°C
·IP rating: IP30 metal case
·Dimension: 41 x 70 x 115 mm
·Weigth: 284g
