Electrical Characteristics
Specifications
·Gender: Female
·No. of contacts: 6
·Current rating: 1A
·Voltage rating: 100V AC
·Orientation: Straight
·Contact resistance: 30mΩ Max. (pin)/50mΩ Max. (shell)
·Insulation resistance: 100MΩ Min. at 500VDC
·Voltage Withstand: 250VAC for 1 minute
·Mounting type: Cable mount
·Contact termination: Solder
Materials
·Shell cover: EVA + LLDPE
·Shield cover A: Steel nickel plated
·Shield cover B: Steel nickel plated
·Housing: ABS
·Terminals: Copper silver plated
