Overview

Toggle Switch – Manual Lever Control Switch
Toggle switches are lever-operated switches for dependable on-off or multi-position control. Used in machinery, control panels, marine, and automotive systems, they come in multiple sizes, mounting styles, and voltage ratings.

Specifications

·Rating: 5A 120VAC / 2A 250VAC
·Switch operation: On-off
·Contact configuration: SPST
·Mounting type: Panel mount
·Terminal type: Solder
·Contact resistance: 10mΩ Max. initial @2-4V DC, 100mA for both silver and gold plated contacts
·Insulation resistance: 1000MΩ Min. at 500VDC
·Withstand voltage: 1000VAC for 1 minute
·Operating temperature: -30°C to 130°C
·Electrical life: 50,000 make-and-break cycles at full load
