Electrical Characteristics
Features
·Base with anodized treatment to stand high frequency
·Durable AL nameplate stands static interference
·Using phosphor bronze / nickel to get lasting endurance of insertion hole
·Exquisite colour coordinates for easy recognition
·High - class acetal ABS material of plastic
Specifications
·Tie points: 830
·Hole type: Square
·Insertion range: 0.4-0.7mm
·Contact life: 50,000 times
·Heat distortion temperature : 84°C
Materials
·Plastic: ABS
·Surface: Colored
·Plate: Aluminum
·Surface: Metal
·Thickness: 0.3mm
·Spring clip contact: Phosphor bronze, nickel plated
·Packing: Blister
Accessories
·Plate: 164 x 52 x 0.3mm
·Board: 165.1 x 54.6 x 8.5mm
·1 Terminal strip
·2 Distribution strips
