Electrical Characteristics
Specifications
·Gender: Male
·No. of contacts: 3 contacts
·Mounting type: Cable mount
·Orientation: Right angle
·Termination: Crimp
·Contact resistance: 30mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Withstand voltage: 500VAC for 1 minute
Materials
·Contact: Brass, nickel plated
·Insulator: Nylon 66 + 30% fiber
·Cover: PE, black
