Electrical Characteristics
Specifications
·Gender: Female
·Rating: 16A 250VAC / 20A 250VAC
·Mounting: Panel mount
·Body orientation: Straight
·Termination: Quick connect
·Faston terminals: 4.8 x 0.8mm
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 2000VAC for 1 minute
Materials
·Body: Thermoplastic UL94V-0 or UL94V-2
