Electrical Characteristics
Specifications
·Gender: Female
·Current rating: 6A
·Voltage rating: 125VAC
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 1000VAC for 1 minute
·Mounting: Panel mount
·Termination: Solder
·Color: Red, black, green or yellow
·Length: 24.2 mm
Materials
·Solder pin: C2680 copper, nickel plated
·Housing: PA66, Dupont 101L UL94V2
·Washer: EK7, nickel plated
·Nut: Steel, nickel plated
