Electrical Characteristics
Specifications
·Power supply: 10-30VDC
·Current consumption: 10mA Max.
·Output current: 150mA Max.
·Operation distance: 5mm±10% Max.
·Secure sensing range: 0 to 4mm
·Standard sensing object: Iron steel 18x18x1mm
·Residual voltage: 1.5V Max. at 150mA sink current
·Hysteresis: 15% or less of operation distance
·Response frequency: 600Hz
·Degree of protection: IP67
·Operating temperature: -20°C to +70°C
·Humidity temperature: 95% RH Max.
·Cable length: 2M
Materials
·Detection surface: POM
·Housing: Brass nickel plated
·Wire: PVC oil resistance
