Electrical Characteristics
Specifications
·Rating: 0.1 A 30VDC
·Operating mode: Self-lock
·Contact rssistsnce: 50mΩ Max. (initial)
·Insulation resistance: 100MΩ Min. at 250VDC
·Withstand voltaqe: 250VAC for 1 minute
·Position travel: 1.5±0.2mm
·Mechanical life: 100,000 cycles
·Electrical life: 10,000 cycles
·Operating force: 160±80 gf
·Operating temperature: -25°C to +65°C
·Soldering temperature: 350°C~360°C for 3 second
·Ambient humidity used: 85% RH Max.
Materials
·Stem: POM
·Case: POM
·Base: PBT
·Terminals: C2680
·Sprint plate: C5210
·Spring: SUS304
·Fixed rod: SUS304
