Automotive receptacle contact for using Econoseal J-Mark II connector 22-20AWG
5K pcs in a reel
這個產品無法線上訂購,請發送詢問!
尺寸圖
電器特性

Specifications

·Type: Automotive connector
·Series: MX23A series connector
·Gender: Female
·Current rating: 9A Max.
·Voltage drop: 3mV/A
·Isolation resistance: 100MΩ
·Dielectric resistance: 1000VAC
·Termination method: Crimp
·Operating temperature: -30°C to +105°C
·Applicable wire size: 22AWG ~ 20AWG

Materials

·Housing: Brass, Pre-tin plated
