電気の特性
Specifications
·Pitch: 2.54mm
·No. of rows: 2
·No. of contacts: 10
·Current rating: 1A
·Mounting type: Through hole
·Orientation: Right angle
·Termination: Solder
·Insulation resistance: 3000MΩ Min.
·Withstand voltage: 500VAC RMS for 1 minute
·Operating temperature: -40°C to +105°C
Materials
·Housing: PBT Glass Filled (UL94V-0), red
·Terminal: Copper Alloy
