Electrical Characteristics
Specifications
·Gender: Male
·Connector type: FME
·Impedance: 50Ω
·Body orientation: Straight
·Mouting type: Cable mount
·Termination: Solder
·Frequency range: 0-3GHz
·Voltage rating: 500VAC
·Contact resistance: 10mΩ Max.
·Insulation resistance: 5000MΩ Min. at 500VDC
·Withstand voltage: 1000VAC for 1 minute
