Electrical Characteristics
Specifications
·Gender: Male
·Current rating: 3A
·Voltage rating: 12V DC
·Mounting type: Cable mount
·Insulation resistance: 100MΩ Min. at 500VDC
·Withstand voltage: 500VAC for 1 minute
Materials
·UP shell cover: ABS
·DN shell cover: ABS
·Screw cap nut: Steel, nickel plated
·Ring cap: Steel, nickel plated
·Screw cap: Brass, nickel plated
·Tip: Brass, nickel plated
·Negative contactor: Steel (K7), nickel plated
·Positive contactor: Brass, nickel plated
·Spring: Steel, nickel plated
·SR: PVC
·Screw & nut: Steel, black
