Electrical Characteristics
Specifications
·Rating: 3A 120VAC or 28VDC / 1A 250VAC or 0.4A 20VAC or DC
·Contact resistance: 10mΩ Max. initial @ 2-4VDC 100mA for silver plated contacts
·Insulation resistance: 1,000MΩ Min.
·Dieletric strength: 1,000V RMS @ sea level
·Electrical life: 50,000 make-and-break cycles at full load
·Operating temperature: -30°C to +130°C
Materials
·Case: Diallyl phthalate (DAP) (UL94V-0)
·Plunger: Polybutylene terephathalate (PBT) (UL94V-0)
·Bushing: Brass, nickel plated
·Housing: Stainless steel
·Terminal/contact: Brass, with silver plated or gold over silver
·Switch support: Brass, tin plated
·Center contact & terminal: Epoxy
